New Three Chamber Continuous Polyelectrolyte Batching Preparation Units

ProMinent Fluid Controls (UK), has introduced the new ATR range of cost-effective three-chamber Ultromat® polyelectrolyte batching systems for liquid polymer solutions prepared from powdered flocculants. The three tanks are cylindrical in shape and serve for preparation, saturation and storage of the polymer solution.

The polypropylene tanks are hydraulically interconnected. Their cylindrical shape is critical to the design and performance of the system. They are extremely stable and do not require additional reinforcement, reducing the weight and transport costs for the

system. In addition mixing is more efficient and, importantly, cost savings in manufacture can be passed on to the customer.

Capable of producing 0.05 to 0.5% flocculant dosing solutions, the ATR range is available in three sizes, with batch quantities of 400, 1000 and 2000 l/hour and is equipped with a control cabinet for fully automatic control of the complete system. The systems are supplied complete with a dry feeder with drive motor, metering pipe heating

and powder hopper with plug-in cover. A wetting system for flushing- in and wetting of the powder includes a wetting cone, flow meter and fitting kit for the in-line water. Two slow running agitators are also supplied.
